Technical data
| Order no. | Measuring range mm | Graduation value mm | Error limit µm | Spindle thread pitch_mm | Error limit |
|---|---|---|---|---|---|
| 4167906 | 175 – 200 | 0,01 | 7 µm | 0.5 mm | 4+(l/100)µm l= length of the combination in mm |
| 4167912 | 250 – 275 | 0,01 | 9 µm | 0.5 mm | 4+(l/100)µm l= length of the combination in mm |
| 4167921 | 275 – 300 | 0,01 | 9 µm | 0.5 mm | 4+(l/100)µm l= length of the combination in mm |
| 4167922 | 150 – 175 | 0,01 | 7 µm | 0.5 mm | 4+(l/100)µm l= length of the combination in mm |
