MAHR Micromar 40 EWRi Digital Micrometer, IP 65

MAHR Micromar 40 EWRi Digital Micrometer, IP 65
MAHR Micromar 40 EWRi Digital Micrometer, IP 65

MAHR Micromar 40 EWRi Digital Micrometer, IP 65

  • High contrast analog display
  • Stainless spindle is hardened throughout and ground
  • Spindle and anvil are carbide-tipped
  • Rapid drive
  • Ratchet is integrated in the thimble
  • Lacquered steel frame, heat insulated
  • Integrated wireless
  • Battery life approx. 3 years (approx. 0.5 in wireless mode)
  • IP 65
  • instruction manual
  • battery
  • setting standard (measuring range of 25-50 mm)
  • case
10 mm
Ask a question
Description Iespējas Specifikācija Video

Micromar 40 EWRi Digital Micrometer



Technical data



Order no.Measuring range mmMeasuring range inchResolution mm/inchError limit µmParallel error in µmFlatness in µmSpindle diameterSpindle thread pitch_mmMeasuring force (N)
4157100
0 – 25
0 – 1″
0.001 / .00005″
2 µm
2 µm
0.6 µm
6.5 mm
0.5 mm
5 – 10
4157101
25 – 50
1 – 2″
0.001 / .00005″
2 µm
2 µm
0.6 µm
6.5 mm
0.5 mm
5 – 10
4157102
50 – 75
2 – 3″
0.001 / .00005″
3 µm
3 µm
0.6 µm
6.5 mm
0.5 mm
5 – 10
4157103
75 – 100
3 – 4″
0.001 / .00005″
3 µm
3 µm
0.6 µm
6.5 mm
0.5 mm
5 – 10
4157104
100 – 125
4 – 5″
0.001 / .00005″
6 µm
3 µm
0.6 µm
6.5 mm
0.5 mm
5 – 10
4157105
125 – 150
5 – 6″
0.001 / .00005″
6 µm
3 µm
0.6 µm
6.5 mm
0.5 mm
5 – 10
4157106
150 – 175
6 – 7″
0.001 / .00005″
7 µm
4 µm
0.6 µm
6.5 mm
0.5 mm
5 – 10
4157107
175 – 200
7 – 8″
0.001 / .00005″
7 µm
4 µm
0.6 µm
6.5 mm
0.5 mm
5 – 10



 Functions

  • RESET (set display to zero)
  • ABS (display can be set to zero without losing reference to ORIGIN)
  • mm/inch
  • ORIGIN (for entering a numerical value)
  • LOCK function (key lock)
  • TOL (tolerance and warning limits)
  • HOLD (storage of measured values)
  • DATA (data transmission)
  • Bi-directional data interface (external input option of characteristic values and setting of individual lock functions by software MarCom)
