Technical data
| Order no. | Measuring range mm | Graduation value mm | Error limit µm | Spindle thread pitch_mm | Measuring force (N) |
|---|---|---|---|---|---|
| 4134200 | 0 – 25 | 0,01 | 4 µm | 0.5 mm | 5 – 10 |
| 4134201 | 25 – 50 | 0,01 | 4 µm | 0.5 mm | 5 – 10 |
| 4134202 | 50 – 75 | 0,01 | 5 µm | 0.5 mm | 5 – 10 |
| 4134203 | 75 – 100 | 0,01 | 5 µm | 0.5 mm | 5 – 10 |
Applications
